Engineering calculations and design

In the aviation fuel industry, precise engineering design is a critical factor in ensuring safety and operational efficiency. Gonnix provides Engineering Calculations & Design services based on international standards and proven practical experiences.

Certified design capabilities:

Gonnix is licensed by Faudi Aviation to design, calculate, and manufacture:

• Filter Water Separators

• Micro Filter Vessels

• Manifolds for element installation, especially for vertical vessels

All designs strictly comply with ASME Section VIII Division 1, ensuring mechanical integrity and long-term durability under demanding operating conditions.

Beyond technical drawings, our designs are optimized solutions tailored to specific operating requirements and installation constraints, enabling easy installation, maintenance, and periodic element replacement.

Accurate engineering calculations:

All designs are calculated in accordance with ASME standards, including:

• Shell, head, and bottom thickness

• Operating pressure and temperature

• Material selection

• Bolt tightening torque

• Number and thickness of nozzles, as well as flange design

These calculations help optimize long-term investment costs and minimize operational risks.

Compliance with aviation industry standards:

• EI 1596

• EI 1541

• EI 1581

These standards are essential to ensuring fuel quality and safety in aircraft refueling operations.

International project experiences:

GONNIX has successfully delivered Engineering Calculations & Design projects in:

• Japan

• South Korea

• Europe

• The Middle East

• Vietnam
